AXIOM is a Eurorack module based on the popular concept of the Euclidean Rhythm, where a defined number of HITS is evenly distributed throughout a sequence.
It allows two CV inputs for each if its four lanes – one for the number of HITS in each lane, and a second for either the number of STEPS in each sequence or for an OFFSET to its starting position.
Each sequence can be assigned a different length, causing the rhythms in each lane to move in and out of phase with one another. A pattern of up to 21,840 steps is possible before repeating if the right settings are chosen!*
An internal clock or external CV trigger can be used to progress the sequencer.
AXIOM is available as either a DIY Kit or as a fully assembled product.
For more information please see the Manuals & DIY Instructions page or the AXIOM YouTube Playlist.
*Hint – use STEPS MODE and set the STEPS values to 13, 14, 15 and 16.
AXIOM - Euclidean Rhythm Generator
Tech Specs
Width – 20HP
Depth – 30mm (including ribbon connector)
Outputs – 2ms pulses at 6.5V
Trigger Inputs – Respond to rising edge triggers of 0-3V or greater
CV Inputs – Operate over the full range of available values when presented with -5V to +5V
+5V Current Draw – 38mA
+12V Current Draw – 26mA
-12V Current Draw – 2mA
